Abacus
Variante wählen:
The most important information
| Altersgruppe ? | 2+ |
|---|---|
| Einsatzgebiete ? | supervised playgrounds |
| Benutzeranzahl ? | 3 Personen |
| Aktivitäten ? | Manual activity |
Technical data
| Gerätelänge ? | 0,95 m |
|---|---|
| Gerätebreite ? | 0,15 m |
| Gerätehöhe ? | 1,50 m |
| Freie Fallhöhe ? | 0,00 m |
| Podesthöhen | - |
| Gesamtgewicht ? | 60.00 kg |
| Schwerstes Einzelteil ? | 20.00 kg |
| Mindestraumlänge ? | 3,95 m |
| Mindestraumbreite ? | 3,15 m |
| Mindestraumhöhe ? | 1,50 m |
Assembly & Foundations
| Montagezeit ? | 1,0 h |
|---|---|
| Monteuranzahl ? | 2 Personen |
| Hebezeug erforderlich | - |
| Fundamente | 040x040x060 |
Product Downloads
Product description
Technical data
Total height: 1.50 m
Base area: 0.15 x 0.95 m
Weight: 20 kg heaviest individual part
60 kg in total
Minimum space: 11 m²
Support post
Standing posts made of robinia plywood, cylindrically milled, Ø 120 mm. Unprotected end grain surfaces are covered with non-detachable stainless steel post caps.
Stainless steel tubular base for the foundation and elevation of Robinia roundwood posts, Ø 120 mm, below the play level.
Attachments
- Slide rule: elements made of polyamide or PVC, Ø 80 mm on axles made of welded stainless steel tube, Ø 20 mm
Metal components: Stainless steel.
The robinia wood is treated with a water-repellent, breathable protective coating. In addition to protecting against moisture, this treatment also reduces cracking. The modular add-on parts transfer their forces directly to the uprights via a special adapter fastening. The screw connections are secured against unauthorised loosening by cover caps.
Foundations (client-provided)
2 units 0.40 x 0.40 x 0.60 m
Concrete volume: 0.19 m³
Assembly time
2 fitters 0.5 hours each
(without foundation)
Suitable for
all age groups,
supervised playgrounds
Manual activities
Item number: 037200700
