Water pump with hand wheel (stainless steel)

Age group ? The specific age group for which the product was developed.

3+
Number of users ? The number of individuals who can use the product simultaneously.

2
Area of use ? The different environments or situations in which the product can be used.

public playgrounds
Product groups ? The categories of similar products.

Water Play Equipment, Water Play Equipment

Technical specifications

Lifting device ? Appropriate hoisting equipment is necessary for assembling the playground equipment.

-

Total length ? The measurement indicating the length of the playground equipment.

0,40 m

Total width ? The measurement indicating the width of the playground equipment.

0,40 m

Total height ? The measurement indicating the height of the playground equipment.

1,19 m

Minimum space length ? The minimum required length for the space where the playground equipment will be placed.

3,40 m

Minimum space width ? The minimum required width for the space where the playground equipment will be placed.

3,40 m

Minimum space height ? The minimum required height for the space where the playground equipment will be placed.

1,19 m

Assembly time ? The time required by qualified individuals to assemble the product.

No specification

Heaviest single piece ? The weight of the heaviest component of the product. This information is crucial for transportation and assembly.

No specification

(Total) Weight ? The total weight of the product. This information is essential for transportation and assembly.

35,00 kg

Free height of fall ? The maximum free fall height of the product, from which the required impact-absorbing surfaces, impact area size, and fall protection requirements can be derived according to (DIN) EN 1176-1:2017.

No specification

Platform heights

-

Product downloads:

Technical data
Height: 1,20 m
Weight: 35 kg as a whole

Suction pipe connection 1 ¼ in (pipe diameter at least ¾ in), welded stainless steel construction, fully encapsulated pump housing, pump mechanism with roller and anti-friction bearing. During winter season, a removal of the upper housing and the hand wheel is indispensable, (winter) cover panel for the bottom part is included with delivery.

Please note:
The installation of the water pump to a pressure water pipe requires a Valve combination (item no. 0-33190-000 or 0-33195-000).
Please also consider the basic technical details given in the installation instructions (such as spacing, pipe diameters etc.); upon request, you will receive them directly from K&K or by downloading the corresponding PDF from www.kaiser-kuehne.com.
