Water spiral (2,00) - Kaiser & Kühne

Age group ? The specific age group for which the product was developed.

3+
Number of users ? The number of individuals who can use the product simultaneously.

1
Area of use ? The different environments or situations in which the product can be used.

public playgrounds
Activities ? The various tasks or actions that can be performed with the product.

manual activity
Product groups ? The categories of similar products.

Water Play Equipment, Water Play Equipment

Technical specifications

Lifting device ? Appropriate hoisting equipment is necessary for assembling the playground equipment.

-

Total length ? The measurement indicating the length of the playground equipment.

2,00 m

Total width ? The measurement indicating the width of the playground equipment.

0,25 m

Total height ? The measurement indicating the height of the playground equipment.

1,88 m

Minimum space length ? The minimum required length for the space where the playground equipment will be placed.

5,00 m

Minimum space width ? The minimum required width for the space where the playground equipment will be placed.

3,25 m

Minimum space height ? The minimum required height for the space where the playground equipment will be placed.

1,88 m

Assembly time ? The time required by qualified individuals to assemble the product.

No specification

Heaviest single piece ? The weight of the heaviest component of the product. This information is crucial for transportation and assembly.

38,00 kg

(Total) Weight ? The total weight of the product. This information is essential for transportation and assembly.

42,00 kg

Free height of fall ? The maximum free fall height of the product, from which the required impact-absorbing surfaces, impact area size, and fall protection requirements can be derived according to (DIN) EN 1176-1:2017.

No specification

Platform heights

-

Foundations

1 pc.

0,70 x 0,30 x 0,30 m
Volume: 0,06 m3

Product downloads:

Technical data
Length of screw pump: 2,00 m
Outer diameter: 250 mm
Weight: 38 kg heaviest single component
42 kg as a whole

Welded structure made of stainless steel with roller bearings, crank handle, support to be set into concrete. Footstep bearing for screw attachment.
At extra charge, there are appropriate pre-fabricated foundations (item no. 15150)

Foundation (on site)
1 pc. 0,30 x 0,70 x 0,30 m

Approximate assembly values:
– delivery as a whole –

Water Play Equipment

Water spiral (2,00) 0-33204-001
