Water Play Equipment

Water pump with handle (stainless steel) 0-33130-001

Download more information (PDF/DWG)

  • CERTIFICATE

  • INSTALLATION INSTRUCTION

  • MAINTENANCE INSTRUCTION

  • DRAWING (2D)

  • DRAWING (3D)

Technical data
Height: 1,17 m
Weight: 35 kg as a whole

Suction pipe connection 1 ¼ in (pipe diametre at least ¾ in), welded stainless steel construction, fully encapsulated pump housing, pump mechanism with roller and anti-friction bearing. During winter season, a removal of the upper housing and the handle is indispensable, (winter) cover panel for the bottom part is included with delivery. Appropriate for installation on a solid surfacing, for example a platform on site.

Please note:
The installation of the water pump to a pressure water pipe requires a K&K Valve combination (item no. 0-33190-000 or 0-33195-000).
If the water supply to the pump (through a clock timer or similar) is interrupted, the pump handle must be safeguarded against operation (for example by the K&K pump latch, item no. 1040639). This prevents a handle setback due to an increasing negative pressure.
Please also consider the basic technical details given in the installation instructions (such as spacing, pipe diametres etc.); upon request, you will receive them directly from K&K or by downloading the corresponding PDF from www.kaiser-kuehne.com.

For your planning, please request more detailed information!
