Play structure 0-25300-502






Ice Palace









Sunny Day


Technical data
Area: 5,80 x 6,90 m
Minimum space: 9,15 x 9,90 m (60 m²)
Total height: 9,25 m
Platform heights: 1,00 m up to 4,20 m
Slide entrance height: 4,30 m

Posts made from stainless steel tubes Ø 12 cm covered by non-detachable protective stainless steel caps.

Platforms from boards of 30 mm thickness and all-round square-shaped joists 45 x 100 mm. Dried timber from Robinia, planed, milled and free from decay. Force-fitting fastening through specific stainless steel brackets with end-to-end bolt assembly.

Attachment parts
– timber infill barriers from Robinia, 125 x 30 mm, fastening between stainless steel tubes Ø 33,7 x 2 mm
– infill barriers from stainless steel tubes, Ø 33,7 x 2 / 25 x 2 mm, one-piece welded assembly
– tandem guardrails from stainless steel tubes, Ø 33,7 x 2 mm
– inclined ramp from Robinia timber with a tandem guardrail from stainless steel tubes with a fixed Herkules climbing rope Ø 18 mm
– sloped scramble up net consisting of Herkules ropes Ø 16 mm fixed to a stainless steel frame
– tower-shaped roof, 72° inclination, from highly weather-resistant HighPressureLaminate panels of 13 mm thickness, round edges, with rotating flag
– trapezoid pent roof from a highly weather-resistant HPL panel of 13 mm thickness, fastening to a frame from stainless steel tubes Ø 33,7 x 2 mm

Helical tunnel slide
Installation height: 4,20 m
Slide entrance height: 4,30 m
Inclination: 30°/38°
(Right-handed) helix: 300°
Tunnel diameter: 0,80 m
Sheet metal thickness: 2,5 mm

Sliding sections from stainless steel, of low noise level thanks to tunnel shape. Due to transport-related reasons, the slide is (in three parts) welded to a centre pylon including appropriate connecting flanges to facilitate installation on site.
Course: Right-handed helix 300°

Robinia timber is furnished with water-repellent, breathable protective coating. Besides protection from moisture, that treatment reduces crack formation. Thanks to a specific fastening adaptor, forces arising from the modular attachment parts are directly derived into the posts. Tamper-proof screw connections thanks to screws with security socket.

For your planning, due to a possible sliding surface heating, please see to a north-east orientation of the slides or provide half-shade of trees.

Foundations (on site)
3 pcs. 0,30 x 0,30 x 0,40 m
12 pcs. 0,50 x 0,50 x 0,60 m
1 pc. 0,80 x 0,80 x 1,00 m
3 pcs. 1,00 x 0,40 x 0,40 m
concrete amount: 3 m³

Free height of fall
2,00 m
