Ball game wall - Kaiser & Kühne

Age group ? The specific age group for which the product was developed.

3+
Number of users ? The number of individuals who can use the product simultaneously.

13
Area of use ? The different environments or situations in which the product can be used.

public playgrounds
Activities ? The various tasks or actions that can be performed with the product.

sporting activity
Product groups ? The categories of similar products.

Ball Games Equipment, Ball Games Equipment

Technical specifications

Lifting device ? Appropriate hoisting equipment is necessary for assembling the playground equipment.

-

Total length ? The measurement indicating the length of the playground equipment.

4,10 m

Total width ? The measurement indicating the width of the playground equipment.

0,63 m

Total height ? The measurement indicating the height of the playground equipment.

2,80 m

Minimum space length ? The minimum required length for the space where the playground equipment will be placed.

No specification

Minimum space width ? The minimum required width for the space where the playground equipment will be placed.

No specification

Minimum space height ? The minimum required height for the space where the playground equipment will be placed.

No specification

Number of installers ? The number of qualified individuals required for product assembly.

2 Pers.

Assembly time ? The time required by qualified individuals to assemble the product.

1 h

Heaviest single piece ? The weight of the heaviest component of the product. This information is crucial for transportation and assembly.

No specification

(Total) Weight ? The total weight of the product. This information is essential for transportation and assembly.

220,00 kg

Free height of fall ? The maximum free fall height of the product, from which the required impact-absorbing surfaces, impact area size, and fall protection requirements can be derived according to (DIN) EN 1176-1:2017.

No specification

Platform heights

-

Foundations

2 pcs.

0,50 x 0,50 x 0,60 m
Volume: 0,15 m3

Classic

Variants finder

Classic

Selected variant:

Please indicate the following variant number when placing your order:

Make contact

This kaiser & kühne product enables:

Product downloads:

Technical data
Total length: 4,10 m
Total height: 2,80 m
Height of the hoops: 2,50 m

– tubular stainless steel frame Ø 76 x 3 mm/ two ring-shaped hoops Ø 38 x 2,5 mm
– target board from a highly weather-resistant coloured HPL panel 20 mm

Foundations (on site)
2 pcs. 0,50 x 0,50 x 0,60 m
concrete amount: 0,30 m³

Aprroximate assembly values
2 mechanics 1 hour each
(without creating foundations)

Appropriate for
all ages,
public playgrounds etc.,
sportive ativity

Ball Games Equipment
