Fitness Equipment

Technical data
Area: 0,12 x 2,82 m
Minimum space: 3,12 x 5,82 m (17 m²)
Total height: 3,52 m
Weight: 55 kg heaviest single piece
135 kg as a whole

Posts: tubular steel Ø 121 x 4 mm, hot-dip galvanised, powder-coating on choice according to RAL colour chart (except luminous or glimmer colours)
Metal components: stainless steel

Please note
The device is optionally available as permanently installed public playground equipment (certified according to EN 1176) or as permanently installed outdoor fitness equipment (certified according to EN 16630).
If it is placed as fitness equipment, information on function and safety must be provided in close proximity. This can be done by means of an optionally available station signboard.

Foundations (on site)
2 pcs. 0,60 x 0,60 x 0,60 m
concrete amount: 0,43 m³

Approximate assembly values
2 mechanics 1 1/2 hours each
(without creating foundations)

Appropriate for
Adults
Fitness trails etc.
physical activity
