Cargo ship 0-30265-502






Ice Palace









Sunny Day


Technical data
Area: 4,65 x 6,40 m
Minimum space: 8,15 x 9,40 m (48 m²)
Total height: 2,45 m
Platform height: 0,40/0,60/0,80 m
Slide installation height: 0,80 m
Slide entrance height: 0,90 m
Slide inclination: 36°
Slide width: 0,60 m
Sliding sheet metal thickness: 2,5 mm
Weight: 70 kg heaviest single piece
850 kg as a whole

Posts made from stainless steel tubes Ø 120 x 3 mm covered by non-detachable protective stainless steel caps.
Upper ends of posts level with platforms are covered by welded-on circular blanks made from stainless steel.

Platforms from boards of 30 mm thickness and all-round square-shaped joists 45 x 100 mm. Dried timber from Robinia, planed, milled and free from decay. Force-fitting fastening through specific stainless steel brackets with end-to-end bolt assembly.

Attachment parts
– timber infill barriers from Robinia, 125 x 30 mm, fastening between stainless steel tubes Ø 33,7 x 2 mm
– sand enclosing element made from Robinia planks 95 x 30 mm, planed, milled and free from decay
– pair of stepped handrails Ø 33,7 x 2 mm
– balcony parapet made from stainless steel tubes
– megaphone with horizontal rotation by 360°
– rubber flag with fabric insert, for fastening on top of a post
– stairs for post attachment made from Robinia 170 x 45 mm, fixed to stainless steel framework Ø 33,7 x 2 mm, step spacing 133 mm
– pair of Robinia infill barriers for the stairs, fastening between stainless steel tubes Ø 33,7 x 2 mm
– wave-shaped counter/bench: made from red highly weather-resistant HPL panel (20 mm thickness)
– attachment slide, width 0,60 m, one-piece welded assembly, stainless steel sheet thickness: 2,5 mm, with roll-off prevention above the entrance section

For your planning, due to a possible sliding surface heating, please see to a north-east orientation of the slides or provide half-shade of trees.

Metal components: stainless steel
Robinia timber is furnished with water-repellent, breathable protective coating. Besides protection from moisture, that treatment reduces crack formation. Thanks to a specific fastening adaptor, forces arising from the modular attachment parts are directly derived into the posts. Tamper-proof connections thanks to screws with security socket.

Foundations (on site)
15 pcs. 0,40 x 0,40 x 0,40 m
1 pc. 0,40 x 0,75 x 0,40 m
concrete amount: 1,08 m³

Approximate assembly values
2 mechanics 5 hours each
(without creating foundations)

Free height of fall
0,90 m

Appropriate for
children from the age of 2 years up,
public playgrounds etc.,
social/physical activity
