Bell climber - Kaiser & Kühne

Age group ? The specific age group for which the product was developed.

5+
Number of users ? The number of individuals who can use the product simultaneously.

3
Area of use ? The different environments or situations in which the product can be used.

public playgrounds
Activities ? The various tasks or actions that can be performed with the product.

climbing
Product groups ? The categories of similar products.

Fitness Equipment

Technical specifications

Lifting device ? Appropriate hoisting equipment is necessary for assembling the playground equipment.

-

Total length ? The measurement indicating the length of the playground equipment.

2,80 m

Total width ? The measurement indicating the width of the playground equipment.

2,45 m

Total height ? The measurement indicating the height of the playground equipment.

4,75 m

Minimum space length ? The minimum required length for the space where the playground equipment will be placed.

6,20 m

Minimum space width ? The minimum required width for the space where the playground equipment will be placed.

6,20 m

Minimum space height ? The minimum required height for the space where the playground equipment will be placed.

4,75 m

Number of installers ? The number of qualified individuals required for product assembly.

3 Pers.

Assembly time ? The time required by qualified individuals to assemble the product.

1 h

Heaviest single piece ? The weight of the heaviest component of the product. This information is crucial for transportation and assembly.

55,00 kg

(Total) Weight ? The total weight of the product. This information is essential for transportation and assembly.

200,00 kg

Free height of fall ? The maximum free fall height of the product, from which the required impact-absorbing surfaces, impact area size, and fall protection requirements can be derived according to (DIN) EN 1176-1:2017.

2,95 m

Platform heights

-

Foundations

3 pcs.

0,60 x 0,60 x 0,60 m
Volume: 0,22 m3

1 pc.

1,60 x 1,60 x 0,40 m
Volume: 0,80 m3

Classic

Variants finder

Classic

Selected variant:

Please indicate the following variant number when placing your order:

Make contact

This kaiser & kühne product enables:

Product downloads:

Technical data
Total height: 4,75 m
Area: 2,45 x 2,80 m
Minimum space: Ø 6,20 m
Weight: 55 kg heaviest single component
200 kg as a whole

– Posts made from stainless steel tubes Ø 12 cm covered by non-detachable protective stainless steel caps.
– Globes: stainless steel Ø 40 cm, acoustic signal generator
– Climbing bars made of stainless steel

Foundations (on site)
3 pcs. 0,60 x 0,60 x 0,60 m
1 pc. Ø 1,60 x 0,40 m
concrete amount: 1,45 m³

Approximate assembly values
3 mechanics 1,5 hours each
(without creating foundations)

Free height of fall
2,95 m

Appropriate for
children from the age of 5 years up,
public playgrounds etc.,
physical activity

Fitness Equipment
